Ritter R803, Dual Spindle Horizontal Boring machine, 230V, 3PH, 1995

Ritter R803, Dual Spindle Horizontal Boring machine, 230V, 3PH, 1995

Will be cleaned and checked at our warehouse.

Specifications below are believed to be correct for this machine, but may need further verification:

(2) 1 HP boring units

• (2) double-spindle drilling heads on 1 in. centers
• (2) pneumatic hold-downs
• foot pedal operation
• 10 in. x 24 in. table

two (2) 1HP TEFC spindle motors with starters, V-belt driving drills. (2) Double Spindle heads. 1” spindle centers on Spindles, 1-1/4” - 11” adjustable spindle centers. 0 - 3” adjustable boring depth. 0-2” spindle Height adjustment. 36” Fixed work Table Height with 12” x 24” work table. Includes foot switch. Currently connected 230 Volt, 3 phase. Machine is approximately 45” x 45”x 56” shipping size 635 lbs.
