Holzma HPP 380/31/31 Horizontal Beam Panel Saw, 2006, 220V, 3PH

Holzma HPP 380/31/31 Horizontal Beam Panel Saw, 2006, 220V, 3PH

$35,000 (USD)

orCall 920-452-4494

Description

Holzma HPP 380/31/31 Horizontal Beam Panel Saw, 2006, 220V, 3PH



Disassembled and ready to load


Specifications below are believed to be correct, but may have to be verified.


Saw blade projection 95 mm (3.74")


Cutting length 3100 (122.1")


Program fence speed** 90 m/min (295 ft/min)


Saw carriage speed 0.1-150 m/min (0.3-492 ft/min)


Main saw motor (frequency-controlled) 21.0 kW (28.6 HP)


Scoring saw motor 2.2 kW (3.0 HP)


Main saw blade 380 (14.96") x 4.4 x 60 mm


“Bombastic” Scoring saw blade 180 (7.09") x 4.4 - 5.4 x 45 mm


Control software CADmatic 4 PROFESSIONAL


Monitor Average 19" TFT flat screen monitor with touch screen


Total air requirements 150 Nl/min (5.3 cfm)


Extraction system 5000 m3 /h, 30 m/sec (2943 cfm)


Operating pressure 6 bar (87 psi)





Specifications

ManufacturerHolzma
ModelHPP 380/31/31
Year2006
ConditionUsed
Stock NumberP-4-280
