Specifications

·        Hopper Opening: 39.4" x 49.2"

·         (1,000 mm x 1,250 mm)

·        Hopper Configuration: 3 straight sides with curved front wall

·        Machine Opening: 39.4" x 39.4"

·        (1000 x 1000 mm)

·        Hopper Volume: 1.47 yds³ (1.1 m³)

·        Rotor: "V-Rotor"

·        Rotor Diameter: 10" (252 mm)

·        Rotor Length: 39.4" (1000 mm)

·        Rotor Speed: 100 RPM +/-*

·        Type of Cutter: 4X indexable concave shape

·        Size of Cutter: 1.57" x 1.57" (40 x 40 mm)

·        # of Cutters: 54

·        Extraction Requirements: 1900 cfm,

·        8” (200 mm) diameter

·        Weight: App 4,630 lbs (2,100 kgs)

·        Power: 460 V / 60 Hz / 3 Phase

·        Screen: 20/25 mm

·        Output**: 1,000 – 1,250 lbs/hr (450-570 kg/hr)

INCLUDED with WL(K) Series (4-8):

·        Control Panel with Star Delta Starter and 16 ft. Cable Bundle

·        Allen Bradley PLC w/ Touch Screen HMI

·        Anti Vibration Feet

·        V-Rotor

·        Two (2) Rows of Rotor Knives

·        Reverse Counter

·        Fast Hydraulic Ram

·        WEIMA Gearbox with Limit Switch

·        Log Spacer Hopper

·        1-Sided Bottom Serrated Ram

Machine History:

Condition: Reconditioned, in good running condition.

Year Mfg: 2018

Electrics: 460/3/60

Serial No.: 510-2677

Below lists key items replaced on machine:

-        Ram guides, belts, rotor knives, broaching knives, counter knives, rotor bearings and seals, main gear box, universal joint.

-        Machine will come with a 30 day warranty.

·        The rotor speed will be determined by the application and is fixed

·        Quoted output is an average and can be influenced by density, material size, screen size, feeding form, and other factors
