Biesse Artech Levia 400, 53" 3 Head Electronic Sectioned Pad Veneer / Finishing Sander, 3PH, Belt Cleaner, Outgoing Panel Cleaning - Brush / Air

Biesse Artech Levia 400, 53" 3 Head Electronic Sectioned Pad Veneer / Finishing Sander, 3PH, Belt Cleaner, Outgoing Panel Cleaning - Brush / Air

$25,000 (USD)

Available quantity: 1

orCall 920-452-4494

Description

Biesse Artech Levia 400, 53" 3 Head Electronic Sectioned Pad Veneer / Finishing Sander, 3PH, Belt Cleaner, Outgoing Panel Cleaning - Brush / Air


2011 Model Year, Some repairs are needed to put back into service. Owner replaced with new sander.



3-group electronic automatic sander calibrator with transversal belt BIESSE ARTECH LEVIA 400



Working width 1350 mm


Min/max working thickness 5/200 mm


Abrasive belt size 1370 x 2620 mm




Composition:


42 sector reading barrier - 32 mm pitch


1st Belt Transversal group with electronic sectioned pad with 42 sectors, 32 mm pitch - Motor with 11 Kw (15 Hp) inverter


2nd Group Electronic sectioned buffer group with 43 sectors - 32 mm pitch - 11 Kw (15 Hp) motor with inverter - Oscillating blower for cleaning the belt


3rd Group Electronic sectioned superfinishing pad group with 42 sectors - 32 mm pitch - 11 Kw (15 Hp) motor with inverter


Oscillating blower for cleaning the abrasive belt


Brush unit with 2.2 kW (3 Hp) motor


with 200 diameter roller with quick change system


Device for lateral oscillation of the brush group


Panel cleaning group with turbo rotary blowers


Vacuum hob with 2.2 kW (3 Hp) electric fan inside the base


Automatic system for regulating the vacuum table according to the absorption of the belt feed motor


40 Shore rubber conveyor belt


Automatic table positioner


Entrance and exit roller conveyor


2.2 Kw (3 Hp) inverter for adjusting the belt advancement speed from 3.5 to 20 m/min


TSP 100 electronic control


N° 3 proportional valve for managing the working pressure of the electronic sectioned pad by electronic control



Overall dimensions:


Machine assembled mm 3200 x 2100 x 2300 h


Machine dismantled: mm 2500 x 2000 x 2300 h


Weight 3115 kg

Specifications

ManufacturerBiesse
ModelBiesse Artech Levia 400 - 1350
Year2011
ConditionUsed
