Laguna Bandit MEB3/2-1035 2mm Capacity Edgebander, 230V, 1PH

Laguna Bandit MEB3/2-1035 2mm Capacity Edgebander, 230V, 1PH

$6,995 (USD)

Available quantity: 1

orCall 920-452-4494

Description




The Laguna Tools Bandit 3/2 is the compact heavy-weight in our line of automatic edgebanders. Designed for every-day professional use with all 2mm materials. The gluepot allows for maximum flexibility for use with PVC, wood tape, laminate and wood strips. Standard features include automatic end trim with dual blade end cutting units, edge trimming with dual high frequency motors, buffing unit, adjustable overhead control panel, pull out support rollers for wide panels, and electronic temperature control with digital readout.


Voltage 220V

Motor Phase 1 Ph

Amperage 40 Amps

Compressed Air Required 87 PSI Clean Dry Air

Tape Thickness (Min-Max) 0.4 mm – 2 m/mIn-feed

Fence Heated

Glue Tank Capacity 30 oz Teflon Coated

Glue Heating 5 Elements with Auto Temperature Control

Glue Applications Micro-Adjustable

Pressure Rollers Dual

Panel Feed Automatic Belt Feed

Work Table Length 79"

Minimum Panel Length 9.44″

Minimum Panel Width 4-3/4″

Panel Thickness (Min – Max) 0.47″ - 1.77″

Dust Collection Port 4"

Edgebanding Coil Capacity Diameter 31-1/2″

End Trim Saw Blade – Front and Rear Automatic

Edge Trim Carbide Insert Shaper Cutters – Top and Bottom

Buffing Top and Bottom

Weight 1200 lbs

Pull-Out Support Standard

Centralized Controls PLC Standard

Specifications

ManufacturerLaguna
ModelMEB3/2-1035
Year2013
ConditionUsed
Stock NumberVT755136
