Weinig OCMS Opticontrol Optical Comparator

As taken from service

Mfg 2007

110V

1 Ph

Working width 300mm/11.8"

Allowable tool dimension of 3" - 11-3/4" head diameter

Measuring stand allows for electronic measuring and indicating of cutter head dimensions with electronic digital readouts

Magnifier screen viewer with 20:1 magnification

Cutterhead placed in Powerlock tool post; operator views through the scope and moves the measuring carriage via precision dialing left to right

Measured values (radial) and (axial), tool dimensions both minimum and maximum are displayed.
